Home > Stainless Steel 316/316L Angles
Aditya Stainless, a reputable manufacturer and supplier based in Kolkata, India, proudly offers a top-notch selection of Stainless Steel 316/316L Angles. These angles are celebrated for their outstanding corrosion resistance and structural integrity, making them perfect for tough environments like marine, chemical, and pharmaceutical sectors. Crafted with precision, SS 316/316L angles boast excellent weldability, formability, and durability. The 316L variant, with its lower carbon content, is particularly suited for applications that demand resistance to sensitization and intergranular corrosion. Aditya Stainless adheres to global standards such as ASTM and ASME, ensuring that they deliver quality products to clients both at home and abroad.
Stainless Steel 316/316L Angles are primarily composed of 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, which enhances their resistance to chlorides and acids. The 316L version features a lower carbon content (<0.03%), which improves weldability and reduces carbide precipitation. In terms of mechanical properties, these angles have a tensile strength ranging from 485 to 620 MPa, yield strength between 170 and 310 MPa, and an elongation of 40%. They also demonstrate remarkable toughness, even at cryogenic temperatures, with a Brinell hardness of up to 217. Their strong chemical composition and mechanical reliability make them ideal for load-bearing and corrosion-sensitive structural applications.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
We conducts a strict quality test and obtains certifications to guarantee the best Stainless Steel 316/316L Angles in terms of strength, corrosion resistance, and accuracy. Each product batch is certified for compliance with international standards and offers clients full assurance in terms of reliability, performance, and conformity to industrial needs for a variety of uses.
Stainless Steel 316/316L angles are L-shaped structural components known for their excellent corrosion resistance, strength, and durability. They are used in marine, chemical, and high-temperature applications for support and reinforcement.
Stainless Steel 316/316L equal angles have two legs of the same length, forming a 90-degree angle. They offer high strength and corrosion resistance, ideal for structural support in demanding environments.
Stainless Steel 316/316L unequal angles have legs of different lengths, creating a 90-degree angle. They provide versatile support and reinforcement in construction and industrial applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L L angles are L-shaped structural components offering high strength, durability, and superior corrosion resistance. They are used for framing and support in marine, chemical, and high-temperature environments.
SS 316/316L T-bar angles are stainless steel sections with a T-shaped profile, providing robust support and stability. They are ideal for structural and framework applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L corner angles are L-shaped sections designed for reinforcing and joining corners. They offer high strength, durability, and excellent corrosion resistance, making them suitable for construction and architectural applications.
SS 316/316L Angles find extensive use in structural frameworks, support brackets, reinforced concrete construction, and the fabrication of equipment across the marine, petrochemical, food processing, and pharmaceutical industries. Their exceptional corrosion resistance makes them a great choice for coastal structures, desalination plants, and chemical storage systems. Additionally, these angles are employed in architectural trim, handrails, industrial shelving, and automotive chassis components. Thanks to their ability to withstand pitting and crevice corrosion, they are a reliable option for various demanding applications.
