Home > Stainless Steel Channels
Aditya Stainless, a prominent manufacturer and supplier located in Kolkata, India, specializes in top-quality Stainless Steel Channels that blend structural strength with outstanding corrosion resistance. Crafted with cutting-edge techniques and precision engineering, these channels come in a variety of grades, sizes, and finishes to cater to a wide range of industrial and architectural needs. Renowned for their durability, ease of fabrication, and ability to withstand harsh environments, Aditya Stainless’s channels find applications in construction, infrastructure, marine, food processing, and chemical industries. The company strictly adheres to international quality standards, ensuring dependable performance and a long service life across various applications.
Stainless Steel Channels are generally produced in grades such as 304, 316, and 202, which contain chromium (16–18%), nickel (8–10.5%), and low carbon (≤0.08%). To boost performance, grade 316 includes molybdenum (2–3%) for enhanced corrosion resistance. These channels demonstrate a tensile strength ranging from 520 to 750 MPa, a yield strength of about 210 to 310 MPa, and an elongation of 40 to 50%. Their mechanical properties ensure excellent structural integrity, weldability, and formability, making them ideal for both load-bearing and aesthetic applications in challenging environments.
| Standard | ASTM A276, ASTM A479 / ASME SA276, ASME SA479 |
| Condition | HRAP |
| Size Range | Base: 80 to 150 mm Side: 40 to 75 mm |
| Thickness | 5 to 6 mm (depending on size) |
| Grades | 304, 316 |
| Processing | Bar cutting |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
Aditya Stainless supplies high-quality materials with a focus on strict testing procedures. All our products go through rigorous testing like hardness testing, chemical analysis through spectro analysis, PMI testing, tensile testing, micro and macro structural tests, pitting resistance, and IGC testing. We assure you of superior performances by these thorough checks. With our quality commitment, we also give all the commercial invoices, packing lists with net and gross weights, box numbers, labels, and a Certificate of Origin legalized or attested by the Chamber of Commerce or Embassy. Third-Party Inspection Certificate will also ensure that the customers are satisfied with our SS Channel’s pricing and delivery.
Choose stainless steel channels based on your project’s required strength, corrosion resistance, and environmental conditions. Consider factors like size, grade, and finish to ensure compatibility with your application.
Yes, we provide stainless steel channels in custom sizes and polishes based on your specifications. For more details mail us on sales@adityastainless.co.in
Stainless Steel Channels are widely utilized in construction and infrastructure projects for structural frameworks, support systems, and load-bearing components, thanks to their strength and corrosion resistance. In the food and beverage sector, they are employed for equipment frames, shelving, and hygienic surfaces. They also play a crucial role in marine settings, chemical processing facilities, and wastewater treatment plants, where exposure to corrosive elements is common. Additional applications include railings, architectural trims, bridges, machine supports, and automotive chassis. Their versatility and resilience make them a go-to choice for various demanding environments.
