Aditya Stainless, based in Kolkata, India, stands out as a top manufacturer and supplier of Stainless Steel EFW (Electric Fusion Welded) Pipes. These pipes are celebrated for their exceptional strength, resistance to corrosion, and precise dimensional accuracy. Crafted from high-quality stainless steel and utilizing cutting-edge welding techniques, our EFW pipes deliver seamless performance even in high-pressure and corrosive settings. Available in various grades like 304, 316, and 310, they meet international standards for industrial reliability. Aditya Stainless caters to industries such as oil & gas, petrochemicals, power generation, and water treatment, providing robust and efficient piping solutions designed for demanding applications.
Stainless Steel EFW Pipes are mainly offered in grades such as 304, 316, and 310. Their typical composition features chromium (18–25%), nickel (8–20%), and molybdenum (2–3% in 316), which contribute to their outstanding corrosion resistance and strength. These pipes boast a tensile strength ranging from 500–750 MPa and a yield strength of about 200–350 MPa, with elongation reaching up to 40%. EFW pipes are known for their excellent weldability, high-temperature resistance, and ability to handle pressure. The smooth internal finish minimizes flow resistance, while their mechanical integrity and metallurgical stability make them perfect for both corrosive and high-temperature applications.
| Range : | 1/8” NB to 36” NB, 1/4” OD to 36” OD |
|---|---|
| Outer Diameter : | 6.35 mm O.D to 114.3 mm O.D |
| Thickness : | 0.8 mm to 12.7 mm |
| Length : | up to 26 Meters |
| Specifications : | ASTM A312 / ASTM SA312 |
| Types : | As Welded, EFW, ERW |
| End : | Plain End, Beveled End |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304 | min. max. | – 0.08 | – 2.0 | – 0.75 | – 0.045 | – 0.030 | 18.0 20.0 | – | 8.0 10.5 | – 0.10 |
| 304L | min. max. | – 0.030 | – 2.0 | – 0.75 | – 0.045 | – 0.030 | 18.0 20.0 | – | 8.0 12.0 | – 0.10 |
| 304H | min. max. | 0.04 0.10 | – 2.0 | – 0.75 | -0.045 | – 0.030 | 18.0 20.0 | – | 8.0 10.5 | – |
| Element | SS 304 |
|---|---|
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
| Elongation | 35 % |
Contact us to get a quick quote for your requirement.
We perform high-quality testing on our materials before delivering them to customers. The tests performed are hardness check, chemical analysis, PMI testing, flattening tests, micro and macro examination. All necessary documents such as sales invoice, packing lists, certificates of origin, and a quality assurance letter are provided. For extra peace of mind, customers can ask for third-party inspection reports.
Yes, Stainless Steel EFW pipes can be used for underground applications due to their corrosion resistance, strength, and durability, making them ideal for transporting fluids and gases in harsh environments.
To select the right Stainless Steel EFW pipes, consider factors like the material grade, pipe size, pressure requirements, environmental conditions, and compatibility with the substances being transported. Consult with an expert if needed.
Stainless Steel EFW pipes are sized based on their nominal diameter (ND) and wall thickness, which determine their strength, pressure capacity, and suitability for various applications. Standard sizing follows industry specifications.
Common grades of stainless steel used in EFW pipe manufacturing include 304, 316, 316L, and 321. These grades offer excellent corrosion resistance, strength, and durability for various industrial applications.
Stainless Steel EFW Pipes find extensive use in transporting oil and gas, chemical processing, refineries, and power generation plants, thanks to their corrosion resistance and structural strength. They are particularly suited for boilers, heat exchangers, condensers, and desalination systems, where high pressure and temperature resistance are crucial. In sectors like water treatment, food processing, and pharmaceuticals, they ensure hygiene and durability. Additionally, EFW pipes are utilized in architectural structures, showcasing their versatility and reliability across various demanding applications.
